8 Applications - Getting Started
8.1 Overview
Applications are predefined programs, that cover a wide spectrum of surveying duties and facili-
tate daily work in the field. The following applications are available:
•
Surveying
•
Free Station
•
Tie Distance
•
Area
•
Remote Height
•
COGO
•
Road
8.2 Starting an App
1. Select Program (2) from the Main Menu.
2. To toggle through the available screens, press the PAGE key.
3. To select an application in the Program menu, press a function key, F1 - F4.
Pre-settings for Surveying is shown as an example. Any additional settings for particular applica-
tions are explained within the chapters for those applications.
[ * ] = Setting has been made.
[ ] = Setting has not been made.
F1-F4 To select menu item.
Field Description
Set Job To define the job where data will be saved. Refer to "8.3 Selecting the
Job".
Set STA To define the current position of the instrument station. Refer to "8.4
Selecting the Station".
Set B.S. To define the orientation and horizontal direction of the instrument station.
Refer to "8.5 Selecting the Orientation".
Start Starts the selected application.
8.3 Selecting the Job
All data is saved in Jobs, like file directories. Jobs contain measurement data of different types,
for example measurements, codes, fixpoints or stations. Jobs are individually manageable and
can be exported, edited or deleted separately.
1. Select Program (2) from the Main Menu.
2. To select an application in the Program menu, press a function key, F1 - F4.
3. Select Set Job (1) in the pre-settings screen of the application.
Description
Access
Pre-settings screens
Description
Access
Applications - Getting Started 45
