Field Description Application
Perpendicular offset: Positive if stakeout point is to
the right of the reference line.
Reference Line
DTrav. Perpendicular offset:
Positive if stakeout point is to the left of the meas-
ured point. (←)
Negative if stakeout point is to the right of the
measured point. (←)
Stakeout
Calculated distance perpendicular from the refer-
ence line.
Reference Line
VA Vertical angle to the point. Commonly used
VD Height to the point. Commonly used
DY/E Easting offset:
Positive if stakeout point is to the right of the
measured point.
Negative if stakeout point is to the left of the
measured point.
Stakeout
DY/N Northing offset:
Positive if stakeout point is further away from the
station than the measured point.
Negative if stakeout point is closer to the station
than the measured point.
Stakeout
DZ/H Height offset:
Positive if stakeout point is lower than the meas-
ured point. (↓)
Negative if stakeout point is higher than the
measured point. (↑)
Stakeout
Z Height coordinate of the point. Commonly used
Height offset: Positive if stakeout point is higher
than the reference line.
Reference Line
•
Horizontal distance to first base point
•
Horizontal distance to centre or start point
•
Horizontal distance to start or end point
Commonly used
D Horizontal distance between point 1 and point 2. Tie Distance
D Horizontal offset:
Positive if stakeout point is further away from the
station than the measured point. (↓)
Negative if stakeout point is closer to the station
than the measured point. (↑)
Stakeout
Road Stakeoutt
D Slope distance between point 1 and point 2. Tie Distance
Height of first base point Reference Line
•
Height to the centre or start point
•
Height to the start or end point
Reference Arc
D Height offset:
Positive if stakeout point is lower than the meas-
ured point. (↓)
Negative if stakeout point is higher than the
measured point. (↑)
Stakeout
Road Stakeout
D Height difference between point 1 and point 2. Tie Distance
Calculated height difference relative to the defined
reference height.
Reference Line
Calculated height difference relative to the start
point of the arc.
Positive if stakeout point is higher than the start
point.
Reference Arc
Application 53
