Gas volumes, flows and leakages associated with the breathing system are stated in the
technical specifications and adhere to BTPS reference conditions. (Body temperature, ambient
pressure, Saturated).
All gas concentration readings are normally referenced to dry gas conditions, ambient room
temperature and atmospheric pressure (ATPD).
The condition for measured inlet gas pressures and flows is STPD (Standard Temperature and
Pressure Dry); 20° C, standard pressure at 101.3 kPa and 0 % relative humidity (dry).
13.1 System properties
C40C30C20
Weight and dimensions
140 kg140 kg138 kg (2 drawers)
143 kg (3 drawers)
Base system weight (out of the box
weight)
166 kg166 kg164 kg (2 drawers)
169 kg (3 drawers)
System nominal weight
22
273 kg243 kg353 kg (2 drawers)
363 kg (3 drawers)
System max weight including maximum
load
16.0" x 35.3"
(measured over
table-top and grips)
27.2" x 38.8"27.2" x 38.8"Dimensions of base plate
24.9"32.9" - 40.4"
(adjustable)
N/AHeight (1 drawer)
31.6"N/A33.9"Height (2 drawers)
N/AN/A40.6"Height (3 drawers)
1-2 (1 lockable)1 (lockable)2-3 (1 lockable)Drawers
444Vertical shafts for optional horizontal rails
Three wheels
(diameter 2.0")
Four wheels
(diameter 5.9") with
separate brakes
Four wheels
(diameter 5.9") with
separate brakes
Wheels
Approx. 16.5" x 23.6"Working surface/writing table
15.6" x 9.8"Additional writing table
Adjustable LED light integrated into the display armReading lamp
Display
LED touch screen, complete with 11 membrane switches and one
rotary knob
Type
17.0" x 11.6"Size
Attached to display armPlacement
15"Viewing area
Up to 6 waveforms, user configurableWaveforms
Trends • Graphic display, 1 to 24 hour resolution
• Numeric display, 1 to 60 minute resolution
22. Equipped with two full vaporizers, two gas outlets, one auxiliary O2 and suction module, two rails, two rail clamps,
one absorber, breathing tubes, and one patient monitor.
266
FLOW-i 4.2, User's Manual
| 13
| Technical specifications |
