Getinge Maquet FLOW-i 4.2 User Manual

13.3 Weight and maximum load - accessories
C40, max
load (lbs)
24
C30, max
load (lbs)
23
C20, max
load (lbs)
Equipment
weight
Accessory/Option
1111114.5Additional writing table
111111N/ADrawer
303030N/APatient monitor mounting position
5.55.55.5N/AAuxiliary O
2
& Suction module mounting
position
1111116.6Parameter box support arm
111144N/AWorking surface/writing table
11 lbs per
shaft
11 lbs per
shaft
11 lbs per
shaft
24 vertical shafts
6.66.66.6N/AHorizontal rails for hanging accessories
2626
25
265.8Additional arm
N/A141420Backup Gas Rack
7. 57. 5
12
7. 55.5Extra backup gas holder (incl. full gas
cylinder)
4444441Top shelf
26
444N/AVaporizer holder
N/A66662Universal bracket
N/AN/A662Universal bracket (C20)
23. To maintain the lift function, the combined load on the extra equipment and accessories should not exceed 66
lbs.
24. Maximum configuration is dependant on the lift capacity (minimum requirement 440 lbs) of ceiling pendants
approved for C40 and the maximum capacity of the C40-pendant interface (550 lbs). This gives a range of approx.
110-220 lbs for accessories and extra equipment, depending on the ceiling pendant.
25. C30 can only be equipped with the additional arm or the extra backup gas holder.
26. The system can be equipped with either Top shelf or Patient monitor.
268
FLOW-i 4.2, User's Manual
| 13
| Technical specifications |
