Getinge Maquet FLOW-i 4.2 User Manual

4.8 Emergency ventilation
4.8.1 Manual check of Emergency
ventilation system
To test its operation, perform the following:
1. Activate the Emergency ventilation system
using the activation switch for emergency
ventilation.
2. Set the O
2
flow to 10 l/min - the current
flow is indicated on the flowmeter when
the center of the ball is aligned with the
printed scale.
3. Check at various APL settings that the
test lung can be ventilated using the
Manual breathing bag.
APL
mbar / cmH
2
O
O
2
I/min
O
2
I/min
2
4
6
8
10
Not for use with AFGO
1 3
2
If the emergency ventilation is activated, either
during a patient case or when testing the
system, the emergency ventilation APL valve
must be set to minimum before resuming
normal ventilation (AUTO or MAN) or starting
a new patient case.
CAUTIONS:
• The emergency flow is always delivered
via the patient cassette outlet and thus
the patient tubings must always be
connected to patient cassette outlets
when emergency ventilation is used.
• Staff working with the system should
practise regularly using the emergency
ventilation system.
64
FLOW-i 4.2, User's Manual
| 4
| Startup and system checkout |
