Getinge Maquet FLOW-i 4.2 User Manual

4.4 Vaporizer check
Performs a leakage check of the manual and
automatic breathing circuits and a check of
vaporizer functionality. It shall be performed
after a vaporizer has been connected to the
system.
The first part is identical to the Leakage check
and is made to ensure that no agents leak out
into the operating room during Run mode.
01-01 13 00
3
2
1
5
6
4
Vaporizer check preparatory phase contains
six steps, equivalent to steps 1 to 6 performed
during the Full system check, see section
4.2.1.
If any of the connected vaporizers contain
<5% of the total agent volume, the automatic
vaporizer test will not be initiated for that
vaporizer. A prompt window appears. Pressing
'bypass test' will exclude that vaporizer from
the check. Pressing 'redo test' will repeat the
test.
01-01 13 00
1 2 3
The automatic check sequence includes
vaporizer checks in addition to the automatic
and manual breathing circuit leakage checks.
A summary of the Leakage check and the
Vaporizer check results is displayed after the
automatic check. Press the Standby touch
pad to enter Standby mode or press any of
the touch pads marked 1-3 to repeat any of
the checks.
When the vaporizer is connected and active,
the Agent concentration touch pad displays
the name of the agent, and the agent
concentration is by default set to OFF.
60
FLOW-i 4.2, User's Manual
| 4
| Startup and system checkout |
