Getinge Maquet FLOW-i 4.2 User Manual

13.14 Auxiliary O
2
and suction module (option)
Auxiliary O
2
and suction module
Approx. 4.9Weight (lbs)
300-650 kPa/3-6.5 bar/44-94 PSI
30
Patient suction supply pressure
(Air)
300-650 kPa/3-6.5 bar/44-94 PSI
36
Auxiliary O
2
supply pressure
0 to 10 l/min. Apparent gas flow will increase with altitude as the
ambient pressure decreases.
Auxiliary O
2
flow range
50 - 90 Nl/min
31
at a supply pressure ranging from 3.0 to 6.5 barCompressed air consumption
(Suction unit)
28 Nl/minMax free flow (suction flow)
-60 kPa down to -90 kPa at a supply pressure ranging from 3.0 to
6.5 bar
Max. vacuum (suction)
32
13.15 Misc. optional equipment
Misc. optional equipment
Vaporizer holder
Approx. 0.8 kgWeight
Approx. 4.0 kgWeight including full vaporizer
W 90 x H 220 x L 215 mmDimensions
EVAC Restrictor
Approx. 60 gWeight
W 32 x H 48 x L 48 mmDimensions
Manual breathing bag support arm
Approx. 2.2 lbsWeight
2.2 lbsMaximum load
30. The unit will not meet specified performance if supply pressure is below this range
31. Normal liter (Nl) - volume of gas given ambient conditions, e.g. current atmospheric pressure
32. Max. vacuum varies as a function of atmospheric pressure and supply pressure. Highest performance is obtained
at sea level when the supply pressure is approx. 4 bar. Performance decreases with increased altitude.
278
FLOW-i 4.2, User's Manual
| 13
| Technical specifications |
