13.19 Alarms
Alarms
0.5 - 60 l/minExpiratory Minute Volume: High
0.01 - 40 l/minExpiratory Minute Volume: Low
The difference between the maximum and minimum pressures during
inspiration is too low
Excessive leakage
10 to 120 cmH
2
OAirway pressure: High
Activated when the measured airway pressure exceeds predefined
values for more than 15 seconds. Predefined values depend on
current APL setting.
Continuous APL pressure (manual
mode only)
Airway pressure is constant above set PEEP level +15 cmH
2
O more
than 15 seconds.
High continuous pressure
(automatic mode only)
Measured airway pressure is below -10 cmH
2
O for more than one
second
Negative airway pressure
Permissible pressure limits pre-set tidal volumeRegulated Pressure Limited
(PRVC mode only)
0 - 55 cmH
2
OPEEP: High
0 - 47 cmH
2
OPEEP: Low
1 - 140 B/min and OFFRespiratory rate: High
1 - 140 B/min and OFFRespiratory rate: Low
5 - 45 s and OFFApnea
No breath detection for up to 120 sLong apnea (manual mode only)
Pressure controlled administered breath detected in pressure support
backup mode due to time out of the backup respiratory rate
parameter.
Backup ventilation
Activated when inspiratory and expiratory pressures fail to meet
preset requirements
Check breathing circuit
Less than 18 minutes left of battery operation.Limited battery capacity
Less than 3 minutes left of battery operation.No battery capacity
The gas analyzer has detected that a water trap replacement is
needed
Water trap missing/Replace water
trap
284
FLOW-i 4.2, User's Manual
| 13
| Technical specifications |
