8003 Precision Scalar Analyzer
3-18 Manual 20791, Rev. C, June 2001
3.3.9 Instrument Preset Command Structure
<Device Clear>
Syntax: A standard GPIB device clear (either selective or general) will preset the instrument.
Examples: CLEAR 704: for HP Series Controllers
WRITE GPIB CMD(Dcl): for IBM Series Controllers running TBASIC
Description: A GPIB device clear will cause the instrument to perform an instrument preset. The instru-
ment will go to the following default state:
Function Default Setting
Cursor
Cross Cursor: OFF, frequency at 10000 MHz
Delta Cursor: OFF
Markers: OFF
Active Channel: 1
Sensor
Sensor Mode: DC
Sensor Specific for Source of Frequency: Back Panel Swp Input
Sensor Frequency: 0.05 GHz
Sensor Cal Factor: 0
Sensor Offset: 0
Sensor Full Band Path Cal Option: NO
Display
Setup: Swept Mode
Color Intensity: Red, Green, Blue are bright
Graticule Color: Green
Frequency Label: ON
Title: OFF
Channel
Mode: Swept Frequency
Parameter: A, B, C, A/B for channels 1 through 4.
Color: Cyan, Red, Yellow, Magenta for channels 1
through 4 respectively
Format: dB mode
Memorized Trace: 0
Measurement: Absolute Measurement
Average: OFF, average factor = 8
Smoothing: OFF, smooth apert = 5%
Continue Auto Scale: OFF
Scale per Division: 20 dB
Reference Position: Center
Reference Level: 0 dB
Bandwidth Search Value: -3.00 dB
Channel Search Level: -3.00 dB
CW Mode Setup: REL OFF
Max Hold: OFF
Min Hold: OFF
Channel Title: OFF
Limit Line: OFF
Modulate Bias Voltage: 0 volt
