Operation
Manual 20791, Rev. C, June 2001 2-47
2.5.6 MEMORY Key
[MEMORY]
The FUNCTION
[MEMORY]
key accesses the Store and Recall of instrument setups. These setups
are stored in non-volatile memory and will not be disturbed upon power down. When the MEMORY
key is pressed, the entry area of the display will present a prompt to enter the number of the stored setup
to be recalled. The softkey menu will change to menu F6 shown in Figure 2-12.
The stored setup recall will occur as soon as the setup number is entered. Then the entry area will
indicate the recall is complete, and allow the entry of another setup number to recall if so desired.
[
RECALL N
]
Menu F6: Recalls an instrument setup that was stored using the STORE N softkey. When this soft-
key is pressed, the entry area of the display will present a prompt to enter the number of the setup to
be recalled. When the setup number is entered, the stored instrument setup is recalled. The entry
area will then indicate that the recall is complete, and allow the entry of another setup number to
recall if so desired.
This is the same action that takes place when the MEMORY key is pressed. It is provided here in
case another of the softkeys in the memory menu (such as STORE N to store the current setup) has
been used, and it is then desired to recall a setup.
[
STORE N
]
Menu F6: Stores the current instrument setup as a numbered setup in non-volatile memory. When
this softkey is pressed, the entry area of the display will present a prompt to enter the number under
which the current setup will be stored. When the setup number has been entered, the current setup
will be stored. The entry area of the display will indicate that the storing is complete, and allow the
entry of another number under which to store the current setup if so desired.
[
PREV STATE
]
Menu F6: Undo any Preset conditions and Recall information.
