8003 Precision Scalar Analyzer
B-2 Manual 20791, Rev. C, June 2001
CHANNEL Mode Swept Frequency
Parameter A, B, C A/B for Channels 1 through 4
Color CYAN, RED, YELLOW, MAGENTA for channels
1 through 4 respectively dB Mode.
Format dB mode.
Memorized Trace 0
Measurement Absolute Measurement
Average OFF, average factor = 8
Smoothing OFF, smooth apert = 5%
Continue Auto Scale OFF
Scale per Division 20 dB
Reference Position Center
Reference Level 0 dB
Bandwidth Search Value -3.00 dB
Channel Search Level -3.00 dB
CW Mode Setup REL OFF
Max Hold OFF
Min Hold OFF
Channel Title OFF
Limit Line OFF
Modulate Bias Voltage 0 Volt
SOURCE Signal Source Mode Start/Stop Swept Freq
Start Frequency Sweeper Start Frequency or 1 MHz if not controlled
by the 8003
Stop Frequency Sweeper Stop Frequency
Sweep Time 200 ms
RF Power Level OFF, minimum RF level of the signal source or
0 dBm if not controlled by the 8003.
Source Modulation OFF
Table B-1: 8003 Default Settings (Continued)
Function Default Setting
To Next Page
