System Configuration
Manual 20791, Rev. C, June 2001 B-15
B.6 Connecting Analyzer to an Instrument Controller
The 8003 Analyzer can be remotely controlled via the GPIB (IEEE 488) bus. To connect the 8003
Analyzer to an IEEE 488 compatible Instrument Controller, use the GPIB connection marked “GPIB/
SYSTEM” on the rear panel of the analyzer.
Be sure that the remote controller is connected only to the GPIB/SYSTEM connection as it will not
function if connected to the “PRIVATE” interface.
For further information see the installation and address setting instructions given on page 3-1 of
Chapter 3, REMOTE OPERATION.
NOTE:
This is a different GPIB connector than the “GPIB/PRIVATE” connection used for
sweeper, plotter and printer control.
☛
☛☛
☛
