Giga-tronics 8003 - GPIB Interconnect Cable Connections

System Configuration
Manual 20791, Rev. C, June 2001 B-5
B.3.3.2 GPIB Interconnect Cable Connections
GPIB Connector
Label Out
To Set Sweeper Address
8003 Analyzer GPIB PRIVATE Press: CONFIG → GPIB DEVICES
(softkey) → SOURCE ADRS
(softkey) → 20 → GHz/dB
Giga-tronics (12720A) GPIB Press: CONFIG → GPIB
(softkey) → 20 → GHz
Giga-tronics (7200 Series) REMOTE Press: SPECIAL FUNCTION → A →
S_ADDR (softkey) → 20 →
GHz/dB
Giga-tronics (910 & 610) REMOTE Rear Panel DIP Switches set to:
Position: 1 2 4 8 16
Setting: 001 01
HP 8350 Series or HP 8360 Series HP INTERFACE BUS Press: SHIFT → LCL → 20 → dBm/dB
HP 8340 Series HP INTERFACE BUS Press: SHIFT → LOCAL → 20 → kHz/msec
Marconi 6300 Series SYSTEM Press: SHIFT → STATUS 2 → S_ADDR
(softkey) → 20 → kHz/int
Wiltron 6600B Series IEEE 488 INTERFACE Rear Panel DIP Switches set to:
Position: 1 2 4 8 16
Setting: 001 01
NOTE: If GPIB communication with the Model 8003 is not automatically established when the 8003 and the 6600B
are interconnected and turned on, press the RESET key on the front of the Wiltron 6600B Series instrument.)
Wiltron 6700B Series IEEE 488 INTERFACE Press: SHIFT → ADRS → 20 → ENTER
