Giga-tronics 8003 - Table A-2: Power Sensor Cal Uncertainties

Power Sensors
Manual 20791, Rev. C, June 2001 A-3
See NOTES below
NOTES:
1. The K connector is electrically and mechanically compatible with the APC-3.5 and SMA connectors. Use a Type N(m) to
SMA(f) adapter (P/N 29835) for calibration of power sensors with Type K(m) connectors.
2. For frequencies above 8 GHz, add power linearity to system linearity.
3. Square root of sum of the individual uncertainties squared (RSS).
4. Cal Factor numbers allow for 3% repeatability when connecting attenuator to sensor, and 3% for attenuator measurement
uncertainty and mismatch of sensor/pad combination.
Table A-2: Power Sensor Cal Uncertainties
Freq. (GHz) Root Sum of Squares (RSS) Uncertainties (%)
3
Lower Upper
80301A
80302A
80303A
80304A
80310A
80313A
80314A
80320A
80323A
80324A
80321A
4
80330A
80333A
80334A
Min 1 1.04 1.64 1.58 1.58 4.54 1.58
1 2 1.20 1.73 1.73 1.73 4.67 1.73
2 4 1.33 1.93 1.91 1.91 4.89 1.90
3 6 1.41 2.03 2.02 2.01 5.01 2.01
6 8 1.52 2.08 2.07 2.06 5.12 2.06
8 12.4 1.92 2.55 2.54 2.53 5.56 2.53
12.4 18 2.11 2.83 2.80 2.79 5.89 2.78
18 26.5 —— 3.63 3.68 3.62 —— 3.59
26.5 40 —— 6.05 5.54 5.39 —— 5.30
