Giga-tronics 8003 - Power Sensor Selection Charts; Table A-1: Power Sensor Selection Guide

8003 Precision Scalar Analyzer
A-2 Manual 20791, Rev. C, June 2001
A.2.1 Power Sensor Selection Charts
See NOTES next page
Table A-1: Power Sensor Selection Guide
Model
Freq. Range/
Power Range
Max.
Power
Power Linearity
4
(Freq >8 GHz)
RF
Conn
Lgth. Dia. Wgt VSWR
CW Power Sensors
200 mW Peak Power
80301A
10 MHz to 18 GHz
-70 to +20 dBm
+23 dBm
(200 mW)
-70 to -20 dBm ±0.00 dB
-20 to +20 dBm ±0.05 dB/10 dB
Ty pe N ( m)
50Ω
114.5
mm
(4.5 in)
32 mm
(1.25 in)
0.18 kg
(0.4 lb)
1.12:0.01 - 2 GHz
1.22:2 - 12.4 GHz
1.29:12.4 - 18 GHz
80302A
10 MHz to 18 GHz
-70 to +20 dBm
APC-7
50Ω
80303A
10 MHz to 26.5 GHz
-70 to +20 dBm
-70 to +20 dBm ±0.00 dB
-20 to +20 dBm ±0.1 dB/10dB
Ty pe
K(m)
1
50Ω
1.12:0.01 - 2 GHz
1.22:2 - 12.4 GHz
1.38:12.4 - 18 GHz
1.43:18 - 26.5 GHz
1.92:26.5 - 40 GHz
80304A
10 MHz to 40 GHz
-70 to 0 dBm
-70 to -20 dBm ±0.00 dB
-20 to 0 dBm ±0.2 dB/10 dB
Low VSWR CW
80310A
10 MHz to 18 GHz
-64 to +26 dBm
+29 dBm
(800 mW)
-64 to -14 dBm ±0.00 dB
-14 to + 26 dBm ±0.05 dB/10 dB
Ty pe
K(m)
1
50Ω
127mm
(5.0 in)
32 mm
(1.25 in)
0.23 kg
(0.5lb)
1.13:0.01 - 2 GHz
1.15:2 - 12 GHz
1.23:12 - 18 GHz
1.29:18 - 26.5 GHz
1.50:26.5 - 40 GHz
80313A
10 MHz to 26.5 GHz
-64 to +26 dBm
-64 to -14 dBm ±0.00 dB
-14 to + 26 dBm ±0.1 dB/10 dB
80314A
10 MHz to 40 GHz
-64 to +6 dBm
-64 to -14 dBm ±0.00 dB
-14 to + 6 dBm ±0.2 dB/10 dB
1W CW
80320A
10 MHz to 18 GHz
-60 to +30 dBm
+30 dBm
(1 W)
-60 to -10 dBm ±0.00 dB
-10 to +30 dBm ±0.05 dB/10 dB
Ty pe
K(m)
1
50Ω
127 mm
(5.0 in)
32 mm
(1.25 in)
0.23 kg
(0.5 lb)
1.11:0.01 - 2 GHz
1.12:2 - 12 GHz
1.18:12 - 18 GHz
1.22:18 - 26.5 GHz
1.36:26.5 - 40 GHz
80323A
10 MHz to 26.5 GHz
-60 to +30 dBm
-60 to -10 dBm ±0.00 dB
-10 to +30 dBm ±0.1 dB/10 dB
80324A
10 MHz to 40 GHz
-60 to +10 dBm
-60 to -10 dBm ±0.00 dB
-10 to +10 dBm ±0.2 dB/10 dB
True RMS Sensors (f
m
> 1.5 MHz) (-30 to +20 dBm)
80330A
80333A
80334A
10 MHz to 18 GHz
10 MHZ to 26.5 GHz
10 MHz to 40 GHz
+33 dBm
(2 W)
-30 to +20 dBm ±0.00 dB
Ty pe
K(m)
1
50Ω
152.5
mm
(6.0 in)
32 mm
1.25 in)
0.27 kg
(0.6 lb)
1.12:0.01 - 12 GHz
1.15:12 - 18 GHz
1.18:18 - 26.5 GHz
1.29:26.5 - 40 GHz
Triggerable Pulse Peak Power Sensors (f
m
> 1.5 MHz) (-30 to +20 dBm)
80340A
80343A
50 MHz to 18 GHz
-20 to +20 dBm (Trig.)
-30 to +20 dBm (Free Run)
50MHz to 26.5 GHz
+23 dBm
(200 mW)
±0.13 dB, 0 dBm to -30 dBm
±0.13 dBm, ±0.01 dB/dB
from 0 dBm to +20 dBm
Ty pe
N(m)
1
50Ω
146 mm
(5.75 in)
37 mm
(1.44 in)
0.3 kg
(0.6lb)
1.12:0.01 - 2 GHz
1.22:2 - 12.4 GHz
1.37:12.4 - 18 GHz
80344A 50 MHz to 40 GHz
-20 to 0 dBm (Trig.)
-30 to 0 dBm (Free Run)
±0.13 dB, 0 dBm to -30 dBm Type
K(m)
1
50Ω
1.50:18 - 26.5 GHz
1.92:26.5 - 40 GHz
