Manual 20791, Rev. C, June 2001 B-1
B
System Configuration
B.1 Introduction
This appendix contains the default function settings for the 8003, it also contains instructions for the
proper connection of the most common test equipment and the initial printer installation directions for
the 8003’s ability to generate hardcopies of displayed data and/or plots. It is assumed that the user has
read all manuals for other test equipment in the system, and has set up the test equipment properly.
B.2 8003 Default Parameters
Factory programmed settings of various user definable functions have the following defaults whenever
there have been no changes made to the settings by the operator during any test routines. The default
settings are given for the CURSOR, SENSOR, DISPLAY, CHANNEL and SOURCE component
parameters.
Table B-1: 8003 Default Settings
Function Default Setting
CURSOR Cross Cursor OFF, frequency at 10000 MHz
Delta Cursor OFF
Markers OFF
Active Channel 1
SENSOR Sensor Mode DC
Sensor Specific for Source of Frequency Back Panel SWP Input
Sensor Frequency 0.05 GHz
Sensor Cal Factor 0
Sensor Offset 0
Sensor Full Band
Path Cal Option NO
DISPLAY Setup Swept Mode
Color Intensity RED, GREEN, BLUE are bright
Graticule Color GREEN
Frequency Label ON
Title OFF
