Gorgy Timing LEDI - Dimensions of Clocks and Mountings (in MM)

MDE-LEDI-1099V4.0
21
ENGLISH
1.4. DIMENSIONS OF CLOCKS AND MOUNTINGS (IN MM)
CLOCK
Height of digits
(hours and minutes)
A
B
LEDI
®
5
50
235
145
LEDI
®
5.S
50
315
145
LEDI
®
5.S Hospital
50
375
164
LEDI
®
5.60
50
270
270
LEDI
®
7
70
350
165
LEDI
®
7. OUTDOOR
70
356
171
LEDI
®
7.S
70
430
165
LEDI
®
7.S OUTDOOR
70
436
171
LEDI
®
7.S Hospital
70
490
184
LEDI
®
7.60 & LEDI
®
7.60.S
70
390
390
LEDI
®
10
110
500
210
LEDI
®
10.S
110
640
210
LEDI
®
12 OUTDOOR
110
506
216
LEDI
®
12.S OUTDOOR
110
721
216
LEDI
®
15 OUTDOOR
160
760
315
LEDI
®
15.S OUTDOOR
160
950
315
LEDICA
®
7.M
70
625
165
LEDICA
®
7.M.S
70
715
165
LEDICA
®
ALPHA SQUARE 7.M
70
390
390
LEDICA
®
ALPHA 7.M
70
650
220
LEDICA
®
ALPHA 7.M S
70
760
220
LEDICA
®
ALPHA 7.60.M
70
390
550
LEDICA
®
ALPHA 7.60.M.S
70
390
550
LEDICA
®
10.M
100
770
210
LEDICA
®
10.M.S
100
930
210
