Gorgy Timing LEDI - ASCII RS232 or RS485 Versions; SMPTE Version; Ethernet or Poe NTP Version; Wi-Fi NTP Version

30
MDE-LEDI-1099V4.0
3.1.4. ASCII RS232 or RS485 Versions
► Connect ASCII RS232 or RS485 signal on the plug-in terminal according to table below:
ASCII RS232C
ASCII RS422/485
ASCII 1 Terminal
TXD
E / S -
ASCII 2 Terminal
RXD
E / S +
GND Terminal
GND
GND
► After connecting the ASCII code, press the "reset" button on the back of the product.
3.1.5. SMPTE Version
► Connect SMPTE signal on the terminals "ASCII" and "GND" (No polarity).
3.1.6. Ethernet or PoE NTP Version
► Connect Ethernet cable on Ethernet port located at rear panel of the product.
3.1.7. Wi-Fi NTP Version
► No special connections
3.1.8. TOP Option
► Connect the cable on the both wires outgoing from the clock: brown wire and white wire
► Static relay output: no polarity
► TTL 50 ohms output: brown wire is GND, white wire is positive impulse
► Sine wave output 1000Hz: brown wire is GND, white wire is frequency
3.1.9. ASCII RS232 or RS485 output option
► Connect the ASCII RS232 or RS485 code on the terminal plug following the table below:
ASCII RS232C
ASCII RS422/485
ASCII 1 Terminal
TXD
E / S -
ASCII 2 Terminal
RXD
E / S +
GND Terminal
GND
GND
► After connecting the ASCII code, press « reset » button on the rear of the item.
