Gorgy Timing LEDI - Table of Contents; Contents

4
MDE-LEDI-1099V4.0
CONTENTS
CONTENTS .......................................................................................................................... 4
1. MOUNTING PRINCIPLE ........................................................................................... 9
1.1. WALL MOUNT (LEDI
®
, LEDICA
®
CLOCK) ......................................................................... 9
1.2. FLUSH MOUNT (LEDI
®
, LEDICA
®
CLOCKS) .................................................................. 12
1.3. MOUNTING WITH BRACKET ......................................................................................... 13
1.3.1. Adapter bracket for ceiling mount of LEDI
®
indoor clock single face (small size):
LEDI
®
5(s), LEDI
®
7(s), LEDI
®
5.60(s), LEDI
®
7.60(s). .................................................... 13
1.3.2. Adapter bracket for ceiling mount of LEDI
®
Indoor clock single face (large size):
LEDI
®
10 (s), LEDICA
®
................................................................................................... 13
1.3.3. Ceiling Mounting with bracket for LEDI
®
& LEDICA
®
Indoor clock double face ..... 14
1.3.4. Side Mounting with bracket for LEDI
®
& LEDICA
®
Indoor clock double face ........ 15
1.3.5. Ceiling Mounting with bracket for LEDI
®
outdoor clock single face ........................ 16
1.3.6. Side Mounting with bracket for LEDI
®
outdoor clock single face ........................... 17
1.3.7. Ceiling Mounting with bracket for LEDI
®
outdoor clock double face ...................... 18
1.3.8. Side Mounting with bracket for LEDI
®
outdoor clock double face .......................... 19
1.3.9. Ceiling Mounting with bracket for LEDI
®
World ..................................................... 20
1.4. DIMENSIONS OF CLOCKS AND MOUNTINGS (IN MM) ................................................ 21
2. GENERAL CHARACTERISTICS ............................................................................ 22
2.1. AVAILABLE VERSIONS (ACCORDING TO CLOCK) : .................................................... 22
2.1.1. Standalone version .............................................................................................. 22
2.1.2. Parallel minute impulse input version ................................................................... 22
2.1.3. Series connection ½-minute impulse input version ............................................... 22
2.1.4. DCF24v input Version .......................................................................................... 23
2.1.5. AFNOR NFS 87500 (or IRIG) input version .......................................................... 23
2.1.6. Ethernet version synchronised by NTP (VAC or POE) .......................................... 23
2.1.7. DHW 869.525MHz Radio Version ........................................................................ 23
2.1.8. Radiosynchronised version using a DCF Antenna ................................................ 23
2.1.9. Radiosynchronised version using a TDF Antenna ................................................ 23
2.1.10. Radiosynchronised version using GPS Antenna ................................................. 24
2.1.11. ASCII RS232 or RS485 Version ......................................................................... 24
2.1.12. SMPTE Version.................................................................................................. 25
