► ► Digital display of Hours, Minutes and seconds (“S” option), 7-segment electroluminescent
diodes.
► Tilt of figures: 10°
► Power Supply:
Alternating current: 230 Vac (+/- 10%) / - 50/60 Hz, 115 Vac - 50/60 Hz (option)
Direct current (as option):
► 12VDC, 24VDC : "+" = brown wire; "-" = blue wire
► 48 VDC: no polarity.
Power over Ethernet (option): PoE
► Data saved with a built-in Lithium battery
► 3-colour LED display (red/green/yellow).
► White or blue as optional feature.
► Visual indication of the status of sync via the two second dots (except standalone version)
LEDI
®
range: Standard case – Wall or flush mounted
LEDI
®
REVERSO and LEDI
®
POOL range: Single or dual sided - Wall Mount - Mounting with
ceiling or side bracket
2.1. AVAILABLE VERSIONS (ACCORDING TO CLOCK) :
2.1.1. Standalone version
Built-in 32-KHz TCXO quartz time base
2.1.2. Parallel minute impulse input version
1-minute impulses - Inverted 24V per minute.
Duration of impulse: 0.1sec to 5 sec.
Impulse consumption: 6 mA/24V
Extinction of the two second dots: 120 seconds without synchronization
2.1.3. Series connection ½-minute impulse input version
Series connection with an external 39-Ohm shunt.
½ minute impulses - Inverted every ½ minute.
Duration of impulse: 0.1 sec. to 5 sec.
Impulse consumption: 1.25 V
Line intensity: 60 mA to 120 mA
Extinction of the two second dots: 60 seconds without synchronization
