2.2. AVAILABLE OPTIONS
2.2.1. Pulse Output Option
Output on static relay:
Breaking power : 60 Vdc / 550 mA Selection of open/closed contact by jumpers TTL 50 ohms output
Positive Impulse
Sine Wave 1000Hz (+/- 3%) output
Output level: 2 Volts peak to peak Impedance: 50 ohms
2.2.2. ASCII RS232 or RS485 output option
The clock transmit a code every second
(Configuration: 2400 bauds, size 8 bits, even parity, 1 stop bit):
► Standard mode
The size of this frame is 24 characters with following format
S
T
X
D
A
Y
10
D
D
/
10
M
M
/
10
Y
Y
10
H
H
:
10
m
m
:
10
S
S
C
R
Byte Nr
Field
Size
Value/Meaning
1
STX
1
Start of Text ($02) – mark the beginning of the frame.
2,3,4
D,A,Y
3
The day in the week in a human-readable way (MON, TUE, WED, THU,
FRI, SAT, SUN for Monday to Sunday)
5
1
Space character ($20)
6,7
10D,D
2
Day in the month on two ASCII characters ($30,$31 to $33,$31)
8
/
1
Forward slash character ($2F)
9,10
10M,M
2
Year on two ASCII characters ($30,$30 for 2000 – $39,$39 for 2099)
11
/
1
Forward slash character ($2F)
12,13
10Y,Y
2
Year on two ASCII characters ($30,$30 for 2000 – $39,$39 for 2099)
14,15
2
Two Space characters ($20)
16,17
10H,H
2
Hours on two ASCII characters ($30,$30 to $32,$33)
18
:
1
Colon character ($3A)
19,20
10m,m
2
Minutes on two ASCII characters ($30,$30 to $35,$39)
21
:
1
Colon character ($3A)
22,23
10S,S
2
Seconds on two ASCII characters ($30,$30 to $35,$39)
24
CR
1
Carriage Return ($0D) – mark the end of the frame
The information concerning: the statement of timer, temperature, lightning etc…. are integrated in 12
extra octets.
The first part of information enables to synchronize a computer (in this case, do not consider the
second part).
The complete information sequence is used to control another clock.
