Chapter 21 Setpoints and Logic I/O (OPTIONS) 221
21.1 Setpoint Parameters and Operations 221
Setpoint Setup Parameters
Setpoint Operation
Setpoint Status Mode
Setpoint Inputs
21.2 Setpoint (Input and Output) Parameter Setup 223
21.3 Setpoint Example Setups (Front Panel Entry) 226
21.4 Example Setups 227
Example 1: Over/Under Indicator
Example 2: Grading
Chapter 22 Multi-Scale Inputs (OPTION) 231
22.1 Multi-Scale Option Card 231
22.2 Multi-Scale Parameter Setup 231
22.3 Contents of Multi-Scale kit 232
22.4 Installation 232
22.5 Factory Calibration Information and Setup Instructions 236
22.6 Serial Setup of A/D Board 238
22.7 Setup 238
22.8 Scale Enable 238
22.9 Scale Setup 238
22.10 Scale Calibration 239
22.11 Operation 239
22.12 Selecting the Current Scale 239
22.13 Macros (Selecting a scale) 239
Chapter 23 Multi-Scale (OPTION) 241
23.1 Sample Scale 2# Cell 241
23.2 Contents of Sample-Scale Kit 241
23.3 Load Cell Installation Procedure 241
Chapter 24 Pre-setable Parameters (STANDARD) 247
24.1 Description 247
24.2 Setup 247
