Model 574 Programmable Counting System (PCS)
180 - GSE Scale Systems
can be stored at any one time. If it is necessary to have a
larger number of weights stored, an additional EEPROM
may be installed. Refer to the Number of Rows section
for more information.
17.3 Transmission Setups
There are four separate events which may occur with the
Truck In/Out feature. These are:
Truck In,
Truck Out,
Tare Stored, and
Tare Recalled
The data transmissions sent by the 574 during the four
"Truck In/Out" events are fully programmable and must
be set appropriately in order for the correct results to be
printed. Normally these transmissions are used to print
tickets for the truck's driver however they may also be
for any other purpose, such as printing a log of all truck
activity.
All transmissions are accomplished through the use of
the four Custom Transmits which are part of the
instrument's standard setup. There is a setup parameter
for each event which specifies which of the Custom
Transmits are sent when that event occurs. Any
combination (from none to all) of the four Custom
Transmits may be specified for each event.
Selection Total number
of bytes stored
per truck
weight
Advantages
Limitations
#
0
1
2
3
Name
Seq'n
Small
Big #
ID #6
-Largest possible number of stored
weights for a given amount of
EEPROM installed.
- Automatically assigns truck numbers.
- Allows use of pre-numbered trucks.
- Can permanently store truck tare
weight.
- Allows truck ID numbers up to
16777215.
- Can permanently store truck tare
weight.
- Truck ID may be any size and include
non-numeric characters.
- Can permanently store truck tare
weight.
- Cannot make use of pre-numbered
trucks.
- Cannot permanently store tare
weights.
- Truck ID must be less than 65535.
- Truck ID must be numeric.
- Truck ID must be numeric.
- Uses the largest amount of memory
per stored truck weight.
4
5
6
3 + (P710)*
Table 31 Type of Truck ID P721 Selections
* Note that if selection 3, ID #6, is chosen
then P710 must be set to the size of ID required for
the application. Anywhere from one to 49
characters may be specified.
