Model 574 Programmable Counting System (PCS)
94 - GSE Scale Systems
EXAMPLE #3 Reset a Register Operation
(qty.
total accumulation)
Press <F3> to invoke macro 3. The macro can be
programmed to execute any commands from chapter 16
Macro Operations. The macro can be programmed to
execute any commands from chapter 16 Macro
Operations. However, this example will simply “reset”
the net accumulation register. Any numeric register can
be reset using this routine with a minor modification.
Simply place the following characters into macro #3
“0;31%CDONE!%P”. The previous characters should
appear in the macro table as shown. The following
example is formated as an ASCII file to be uploaded to a
574.
Macro #3 Serial Upload Format
803%s23640%i%e%c%e Gain access to macro 3.
0;31%%C%e Copy “0” to qty. total reg.
DONE!%%P%e Prompt operator for 1 sec.
%z
Other
Remote Operations might include net/gross
accumulations, recall piece weights, update databases,
reset databases, etc. Refer to chapter 16 Macro
Programming Operations for macro commands.
Macro Number
1
2
3
4
5
Local Macro F-Keys on
front keypad
F1
F2
F3
F4
F5
Table 9 Local Macro Keys Associated with their
Specific macro
