Model 574 Programmable Counting System (PCS)
130 - GSE Scale Systems
Selection Example Description
0 "Part #:10-40-5503" ID with name, fixed width
1 "Part #:10-40-5503" ID with name, minimum width
128 "10-40-5503" ID without name, fixed width
129 "10-40-5503" ID without name, minimum width
Table 22 ID Parameter Formats
Selection Description
0 Print the decimal point even if the data has no fractional value
16 Print a + sign for positive data
128 Do NOT print the parameter's name
Table 23 Basic Format Selections
Selection Description
32 Increment number before it is transmitted
36 Decrement number before it is transmitted
64 Increment number after it is transmitted
68 Decrement number after it is transmitted
96 Increment number twice, once before and once after it is transmitted
100 Decrement number twice, once before and once after it is transmitted
Table 24 General Purpose Register Format Selections
Character Description
O Overload or Underload condition
M Motion exists
(space) No Overload or Underload or Motion exists
Table 25 Status Character Interpretation
