GSE Scale Systems - 185
Chapter 17 Truck Weighing Technical Reference Manual
setup parameters are changed which would affect the
format of the stored data (such as changing the size of ID
#6 if ID#6 were selected) or that would change the
remaining amount of storage room (such as modifying
the Custom Transmit setups) then as the changes are
being saved, the unit will warn that the stored In Weights
will have to be cleared. After the Save Mods? ...
ENTER =SAVE prompt and the <ENTER> key is
pressed, the next prompts will be #Rows diff! ... Clr ID
Rows? ... Enter toCLR. Pressing <ENTER> will then
result in Sure? ??? ... Enter toCLR. Pressing <ENTER>
again will then result in the stored weights being printed
out in the same format as described in the Printing the
Stored In Weights section. The standard exit sequence
then proceeds. Pressing any other key will bring the unit
back into the Setup Mode where further changes can be
made before exiting.
17.11 MEMORY USE
The number of rows (incoming weights) which can be
stored in the unit is dependent on how some of the other
features are set up within the unit and on how much
storage memory has been installed.
Access parameter P60000 to see how much storage
memory is currently installed in the instrument. Access
parameter P60001 to see how much of that memory is
not being used. This does not include usage by the Truck
In/Out feature since this feature automatically uses up all
the remaining storage memory. Access parameter
P60005 to determine the actual number of rows which
may be stored with the current configuration. The
amount of storage memory required for each In-Weight
storage is dependent on the selection for parameter P721
and is shown in Table 36, Truck In / Out Memory Usage.
17.12 Example Setups
EXAMPLE #1:
Truck IN/OUT (Sequential ID#)
100%s23640%i%e Access Setup Modes,
Allowing Changes
NAME IN/OUT SEQUENTIAL ID REGISTERS
693%sTRUCK ID#%e P693.-- Reg#3 TRUCK ID#
694%sTRUCK ID#%e P694.-- Reg#4 TRUCK ID#
SETUP INSTRUMENT FOR SEQUENTIAL
TRUCK ID OPERATION
720%s1%e P720.01 IDuse: Truck
721%s0%e P721.00 I.D.# Seq'n
722%s1%e P722.01 In Tx #1
723%s2%e P723.02 OutTx #2
724%s0%e P724.00 TSvTx none
725%s0%e P725.00 TFdTx none
1ST CUSTOM TRANSMIT (TRUCK IN)
1000%s%c1000%e P1000. Custom Transmit #1
SECTION - 17.11
NOTE:
All of the stored truck weights are stored in terms of
displayed increments. Therefore if parameter P111 is
changed, then the stored weights are no longer usable
and they will have to be cleared.
Table 36 Truck In / Out Memory Usage
P721: ID# Bytes per Row
Seq’n 4
Small 5
Big# 6
ID#6 3 plus the value set for
parameter P710, ID 6
size.
