GSE 574 - Table 10 Parameter ID Numbers; Figure 19 Select Key

Model 574 Programmable Counting System (PCS)
98 - GSE Scale Systems
Note:
Parameters 30 through 37 are applicable only to the
counting aspects of the 574 firmware.
Table continued
Parameter ID Transmitted Name
Quantity
30
Qty
Quantity Total
31
Qty TOT
Quantity Total + Current
32
Qty T + C
Quantity Total - Current
33
Qty T - C
Average Piece Weight
34
APW
Average Piece Weight times 1000
35
APW*K
Percent Accuracy
36
% Accy
Last Sample
37
Sampl
Recalled Time
50
R time
Alarm 1 Time (positive number)
51
A1 Tim
Alarm 2 Time (positive number)
52
A2 Tim
Alarm 3 Time (positive number)
53
A3 Tim
Alarm 4 Time (positive number)
54
A4 Tim
Variable #0 (fractional values, real #s, 10
-37
to 10
+37
80
Var #0
Variable #1 (fractional values, real #s, 10
-37
to 10
+37
81
Var #1
Variable #2 (fractional values, real #s, 10
-37
to 10
+37
82
Var #2
Variable #3 (fractional values, real #s, 10
-37
to 10
+37
83
Var #3
Variable #4 (fractional values, real #s, 10
-37
to 10
+37
84
Var #4
Variable #5 (fractional values, real #s, 10
-37
to 10
+37
85
Var #5
Variable #6 (fractional values, real #s, 10
-37
to 10
+37
86
Var #6
Variable #7 (fractional values, real #s, 10
-37
to 10
+37
87
Var #7
Variable #8 (fractional values, real #s, 10
-37
to 10
+37
88
Var #8
Variable #9 (fractional values, real #s, 10
-37
to 10
+37
89
Var #9
Register #1 (whole #s, integer)
91
Reg #1
Register #2 (whole #s, integer)
92
Reg #2
Register #3 (whole #s, integer, + or -)
93
Reg #3
Register #4 (whole #s, integer)
94
Reg #4
Status Character (O, M or <space>)
97
Stat
Currently Displayed Data
98
(variable, depending on current display)
Table 10 Parameter ID Numbers
Figure 19 Select Key
