Model 574 Programmable Counting System (PCS)
222 - GSE Scale Systems
- When the Setup Mode is accessed, all enabled
setpoints are de-activated
- Setpoints based on the Net or Gross Weights
are based upon the weight after it is rounded off
to the selected display increment (set in P111).
SETPOINT STATUS MODE
Once set up for your application, you may check the
status of a particular setpoint by accessing the Setpoint
Status Mode. Its state will continue to be updated while
in this mode. In addition, any or all setpoints can be set
to the active or inactive state.
To reach the Setpoint Status Mode, press <7> <8>
<SELECT>. The numeric display will read SP-01. The
top line of the dot matrix display will indicate whether
the sepoint is enabled or disabled. The bottom line will
read either Activ or DeAct depending upon the current
state of the setpoint.
Once in the Setpoint Status Mode, you can view the
status of a particular setpoint by keying in its number and
pressing <ENTER>. For example, to view the status of
Setpoint 13, press <1> <3> <ENTER>. You may also
view the status of the other setpoints by pressing
<ENTER> once per setpoint or by pressing <UNITS>
or <SAMPLE> which assume up and down arrow cursor
key functions.
You may change the state of any setpoint while it is
being viewed in the Setpoint Status Mode. Press <.>
<1> <ENTER> to activate <Setpoints;Activate> or press
<.> <0> <ENTER> to de-activate <Setpoints;
Deactivate>. To activate or de-activate a setpoint other
than the one you are viewing, key-in its number followed
by the <.> <1> or <.> <0> command. For example, to
select and activate Setpoint #18, press
1 8 <.> <1> <ENTER>
To change all the setpoints to the activated state while in
the Setpoint Status Mode, press
<9> <9> <.> <1> <ENTER>.
Likewise, to de-activate all setpoints, press
<9> <9> <.> <0> <ENTER>.
The serial remote setpoint outputs will not change state
as these commands are executed. Normally a macro is
usually controlling the updating of the serial remote
Parameter Number Setpoint Number
P5100 1
P5200 2
P5300 3
P5400 4
P5500 5
P5600 6
P5700 7
P5800 8
P5900 9
P6000 10
P6100 11
P6200 12
P6300 13
P6400 14
P6500 15
P6600 16
P6700 17
P6800 18
P6900 19
P7000 20
P7100 21
P7200 22
P7300 23
P7400 24
P7500 25
P7600 26
P7700 27
P7800 28
P7900 29
P8000 30
P8100 31
P8200 32
Table 39 Setpoint Numbers
