GSE Scale Systems - 135
Chapter 15 Communications Technical Reference Manual
This is not meant to be a tutorial on the uses of the scan
function. Many resource books are available which go
into much further depth. We have tried to suggest some
possible ways of using it's characteristics to good
advantage.
parameter Setup Reference
Parameter
Selections Description
900 0 Interpreter Disabled
1 Interpreter Enabled
901 0 - 255 Line
TypeTermination
Character
(in the following, X is the input specification number, 1
through 8)
9X0 0 Unused *
1 Character Type
2 Line Type
9X1* Text, Parms, Format
Line control
codes
9X2* 0 - 15 Macro Number
16 No macro
(* when specification Type is set to unused, parameters
9X1 and 9X2 for that specification are not accessible.)
15.10 Input Interpreter Examples
The following input interpreter example shows how the
574 can be programmed to receive a tare followed by a
units identifier. A macro is invoked which tests the
transmitted units name and adjusts the data before storing
it away as the new tare value. Refer to the next few
pages for input interpreter examples.
Example 1: Units identifier
File Name: TAREINP.SET (on disk from GSE)
100%s23640%i%e Access Setup
Modes, Allowing
Changes
700%s12%e P700.-- 1SIZE#1=12
701%sTare units%e P701.-- NAME1 Tare
units
800%s%c%e P800.81 Macro # 0
lb;21%%-%e 0001 subtract
80,2%%C%e 0007 copy register
GOTlbtare!%%P%e 0012 pause
%%N%e 0023 if not
kg;21%%-%e 0024 subtract
.4535925;80%%*%e 0030 multiply
80,2%%C%e 0042 copy register
GOTkgtare!%%P%e 0047 pause
%%N%e 0058 if not
not Tared%%P%e 0059 pause
%%E%e 0070 end if
900%s1%e P900.01 RxInp Enbld
901%s10%e P901.10 RxTrm <LF>
910%s2%e P910.02 RxTyp Line
911%s%c%e P911.04 RxFmt
%e80%e%e Var#0
%e
%e21%e%e ID #1:
.013%e <CR> ^M=13
912%s0%e P912.00 RxMac 0
920%s0%e P920.00 RxTyp
Unusd
930%s0%e P930.00 RxTyp
Unusd
940%s0%e P940.00 RxTyp
Unusd
950%s0%e P950.00 RxTyp
Unusd
960%s0%e P960.00 RxTyp
Unusd
970%s0%e P970.00 RxTyp
Unusd
980%s1%e P980.01 RxTyp Char
981%s%c%e P981.01 RxFmt
.026%e <SUB>^Z=26
982%s16%e P982.16 RxMac
none
%z Exit Setup Mode
Below are two lines of sample data transmissions which
would be converted to lb and stored as tare weights when
received by a 574 with setup specified above:
50kg
50 kg
SECTION - 15.10
To Next Page
