Chapter 4 Parameter Setup (Advanced) Technical Reference Manual
PARAMETER # INFORMATION DESCRIPTION
The following parameters are set aside for scales 2 and 3. The information parameters for scale 1, P61102 through
P61119 holds true for scales 2, 3 and 4 respectively. These parameters will only become apparent when the 2nd and 3rd
scales are enabled. See Parameters 101 through 103.
P61200. Crrnt mV/V Displays an
approximation of the
current mv/V output of
connected load cell or
platform.
Parameters 61201 thru 61221 are all transferable parameters associated with the unique A/D converter on the main
board. Refer to Chapter XX21 for information about Swapping the A/D to another unit.
P61201. CAL Factr Displays fine calibration
factor. This parameter is for
a single point calibration.
This parameter is not
accessable if P129 is enabled
(Multi-point Linearization).
P61202. ReZro Re-Zero Weight
P61203. ZrTrk Wght Displays amount of weight in default
units tracked off by the zero track
feature since last use of the <ZERO>
key.
P61204. CZero %0 Coarse zero value calculated during
calibration. This value is a
combination of parameters 61210 thru
61212.
P61205. Fine Zero XXXXX Fine zero value calculated during
during calibration.
P61206. CGain XX Coarse gain value calculated during
calibration. This value is a
combination of parameters 61213 thru
61216.
P61207. Fine Gain XX Fine gain value calculated during
calibration.
