Chapter 4 Parameter Setup (Advanced) Technical Reference Manual

PARAMETER # INFORMATION DESCRIPTION

SECTION - 4.6

P62000. Dsply Test Performs a display test

when you press

<ENTER>

P64000. Send Setup Will send all current

setup information out a

designated port when

you press <ENTER>

P64100. LnCnt XXXXX Displays the line count

of the setup

ransmission.

P64101. ErCnt XXXXX Displays the number of

errors which have

ocurred on the Indicator

P64102. 1stEr None! Indicates the first error

which occurred on the

Indicator since this

parameter was last

cleared.

P64103. Debug Off/ON Enables/disables

transmission of error

messages out a

designated port as they

occur.

P64200.Macro Debug This parameter will record each

command executed after a macro is

invoked. All branching, sub-routines,

etc. are recorded in the order they are

executed. This is a powerful

troubleshooting tool.
