GW Instek PSW Series User Manual

CONFIGURATION
101
CV Control
F-90
0 = Panel control (local)
1 = External voltage control
2 = External resistance control
(Ext-R 10kΩ = Vo, max)
3 = External resistance control
(Ext-R 10kΩ = 0)
CC Control
F-91
0 = Panel control (local)
1 = External voltage control
2 = External resistance control
(Ext-R 10kΩ = Io,max)
3 = External resistance control
(Ext-R 10kΩ = 0)
Power-ON Output
F-92
0 = OFF at startup
1 = ON at startup
T001 ~ T010 = Run test script TXX at
start up
Master/Slave
F-93
0 = Master/Local
1 = Master/Parallel1
2 = Master/Parallel2
3 = Slave/Parallel
4 = Slave/Series (Only 30V, 80V, 160V
models)
External Out Logic
F-94
0 = High ON, 1 = Low ON
Power Switch trip
F-95
0 = Enable , 1 = Disable
Calibration Settings*
Calibration
F-00
0000 ~ 9999
*Note
Power On and Calibration settings can only be set
during power up.

GW Instek PSW Series Specifications

General

Ripple & Noise (CC)	≤ 3mArms
Protections	OVP, OCP, OTP
Remote Sense	Yes
Programmable	Yes
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Voltage Resolution	1mV
Current Resolution	1mA
Current Accuracy	±0.1% + 10mA
Ripple & Noise (CV)	≤1mVrms
Load Regulation (CC)	≤0.1% + 5mA
Line Regulation (CC)	≤0.1% + 5mA
Remote Interface	USB, RS232
Display	LCD
