GW Instek PSW Series User Manual

APPENDIX
159
Rising current slew rate
F-06
72.00A/s (PSW 30-36)
144.0A/s (PSW 30-72)
216.0A/s (PSW 30-108)
27.00A/s (PSW 80-13.5)
54.00A/s (PSW 80-27)
81.00A/s (PSW 80-40.5)
14.40A/s (PSW 160-7.2)
28.80A/s (PSW 160-14.4)
43.20A/s (PSW 160-21.6)
9.000A/s (PSW 250-4.5)
18.00A/s (PSW 250-9)
27.00A/s (PSW 250-13.5)
2.880A/s (PSW 800-1.44)
5.760A/s (PSW 800-2.88)
8.640A/s (PSW 800-4.32)
Falling current slew rate
F-07
72.00A/s (PSW 30-36)
144.0A/s (PSW 30-72)
216.0A/s (PSW 30-108)
27.00A/s (PSW 80-13.5)
54.00A/s (PSW 80-27)
81.00A/s (PSW 80-40.5)
14.40A/s (PSW 160-7.2)
28.80A/s (PSW 160-14.4)
43.20A/s (PSW 160-21.6)
9.000A/s (PSW 250-4.5)
18.00A/s (PSW 250-9)
27.00A/s (PSW 250-13.5)
2.880A/s (PSW 800-1.44)
5.760A/s (PSW 800-2.88)
8.640A/s (PSW 800-4.32)
Internal resistance
setting
F-08
0.000Ω
Bleeder circuit control
F-09
1 = ON
Buzzer ON/OFF control
F-10
1 = ON
Measurement Average
Setting
F-17
0 = Low
Lock Mode
F-19
0 = Panel lock: allow output off
USB/GPIB setting
Rear Panel USB Mode
F-22
2 = USB CDC
GPIB address
F-23
8

GW Instek PSW Series Specifications

General

Ripple & Noise (CC)	≤ 3mArms
Protections	OVP, OCP, OTP
Remote Sense	Yes
Programmable	Yes
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Voltage Resolution	1mV
Current Resolution	1mA
Current Accuracy	±0.1% + 10mA
Ripple & Noise (CV)	≤1mVrms
Load Regulation (CC)	≤0.1% + 5mA
Line Regulation (CC)	≤0.1% + 5mA
Remote Interface	USB, RS232
Display	LCD
