GW Instek PSW Series User Manual

APPENDIX
165
Input Characteristics
Nominal input rating
100Vac to 240Vac, 50Hz to 60Hz, single
phase
Input voltage range
85Vac ~ 265Vac
Input voltage range
47Hz ~ 63Hz
Maximum input current
100Vac
A
5
200Vac
A
2.5
Inrush current
Less than 25A.
Maximum input power
VA
500
Power factor
100Vac
0.99
200Vac
0.97
Efficiency
100Vac
%
77
78
79
79
80
200Vac
%
79
80
81
81
82
Hold-up time
20ms or greater
Interface Capabilities
USB
TypeA: Host, TypeB: Slave, Speed: 1.1/2.0,
USB Class: CDC(Communications Device
Class)
LAN
MAC Address, DNS IP Address, User
Password, Gateway IP Address, Instrument
IP Address, Subnet Mask
GPIB
Optional: GUG-001 (GPIB to USB Adapter)
Environmental Conditions
Operating temperature
0˚C to 50˚C
Storage temperature
-25˚C to 70˚C
Operating humidity
20% to 85% RH; No condensation
Storage humidity
90% RH or less; No condensation
Altitude
Maximum 2000m

GW Instek PSW Series Specifications

General

Ripple & Noise (CC)	≤ 3mArms
Protections	OVP, OCP, OTP
Remote Sense	Yes
Programmable	Yes
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Voltage Resolution	1mV
Current Resolution	1mA
Current Accuracy	±0.1% + 10mA
Ripple & Noise (CV)	≤1mVrms
Load Regulation (CC)	≤0.1% + 5mA
Line Regulation (CC)	≤0.1% + 5mA
Remote Interface	USB, RS232
Display	LCD
