GW Instek PSW Series - Page 99

CONFIGURATION
99
Internal resistance
setting
F-08
0.000Ω~0.833Ω (PSW 30-36)
0.000Ω~0.417Ω (PSW 30-72)
0.000Ω~0.278Ω (PSW 30-108)
0.000Ω~5.926Ω (PSW 80-13.5)
0.000Ω~2.963Ω (PSW 80-27)
0.000Ω~1.975Ω (PSW 80-40.5)
0.000Ω~22.222Ω (PSW 160-7.2)
0.000Ω~11.111Ω (PSW 160-14.4)
0.000Ω~7.407Ω (PSW 160-21.6)
0.00Ω ~ 55.55Ω (PSW 250-4.5)
0.00Ω ~ 27.77Ω (PSW 250-9)
0.00Ω ~ 18.51Ω (PSW 250-13.5)
0.0Ω ~ 555.5Ω (PSW 800-1.44)
0.0Ω ~ 277.8Ω (PSW 800-2.88)
0.0Ω ~ 185.1Ω (PSW 800-4.32)
Bleeder circuit control
F-09
0 = OFF, 1 = ON
Buzzer ON/OFF control
F-10
0 = OFF, 1 = ON
Measurement Average
Setting
F-17
0 = Low, 1 = Middle, 2 = High
Lock Mode
F-19
0 = Panel lock: allow output off
1 = Panel lock: allow output on/off
USB/GPIB settings
Front panel USB State
F-20
0 = Absent, 1 = Mass Storage
Rear panel USB State
F-21
0 = Absent, 2 = USB-CDC, 3 = GPIB-
USB adapter
Rear panel USB mode
F-22
0 = Disable, 1 = GPIB-USB adapter,
2 = Auto detect speed, 3 = Full speed
only
GPIB address
F-23
0~30
LAN settings
MAC Address-1
F-30
0x00~0xFF
MAC Address-2
F-31
0x00~0xFF
MAC Address-3
F-32
0x00~0xFF
MAC Address-4
F-33
0x00~0xFF
MAC Address-5
F-34
0x00~0xFF
MAC Address-6
F-35
0x00~0xFF
LAN
F-36
0 = Disable, 1 = Enable
DHCP
F-37
0 = Disable, 1 = Enable
IP Address-1
F-39
0~255
IP Address-2
F-40
0~255
