H3C S3100V2-52TP User Manual

89
NOTE:
• A mirroring group can contain multiple source ports.
• On the S3100V2-52TP switch, each port, servin
g
as a unidirectional or bidirectional source port, can be
added to up to two mirroring groups.
Configuring source CPUs for the local mirroring group
Follow these steps to configure source CPUs for a local mirroring group:
To do… Use the command… Remarks
Enter system view system-view —
Configure source CPUs
mirroring-group group-id
mirroring-cpu slot slot-number-list
{ both | inbound | outbound }
Required
By default, no source CPU is configured
for a local mirroring group.
NOTE:
A mirroring group can contain multiple source CPUs.
Configuring the monitor port for the local mirroring group
You can configure the monitor port for a mirroring group in system view, or assign the current port to a
mirroring group as the monitor port in interface view. The two methods lead to the same result.
Configuring the monitor port in system view
Follow these steps to configure the monitor port of a local mirroring group in system view:
To do… Use the command… Remarks
Enter system view system-view —
Configure the monitor port
mirroring-group group-id
monitor-port monitor-port-id
Required
By default, no monitor port is configured
for a local mirroring group.
Configuring the monitor port in interface view
Follow these steps to configure the monitor port of a local mirroring group in interface view:
To do… Use the command… Remarks
Enter system view system-view —
Enter interface view
interface interface-type
interface-number
—
Configure the current port as
the monitor port
[ mirroring-group group-id ]
monitor-port
Required
By default, a port does not serve as the
monitor port for any local mirroring group.
