To do… Use the command… Remarks
Enter system view system-view —
Configure a schedule for
an NQA test group
nqa schedule admin-name
operation-tag start-time
{ hh:mm:ss [ yyyy/mm/dd ]
| now } lifetime { lifetime |
forever }
Required
now specifies the test group starts testing
immediately.
forever specifies that the tests do not stop unless
you use the undo nqa schedule command.
Configure the maximum
number of tests that the
NQA client can
simultaneously perform
nqa agent max-concurrent
number
Optional
By default, the maximum number of tests that the
NQA client can simultaneously perform is 2.
NOTE:
• After an NQA test group is scheduled, you cannot enter the test group view or test type view.
• System adjustment does not affect started or completed test groups. It only affects test groups that
have
not started.
Displaying and maintaining NQA
To do… Use the command… Remarks
Display history records of NQA
test groups
display nqa history [ admin-name operation-tag ] [ |
{ begin | exclude | include } regular-expression ]
Display the current monitoring
results of reaction entries
display nqa reaction counters [ admin-name
operation-tag [ item-number ] ] [ | { begin | exclude |
include } regular-expression ]
Display the results of the last NQA
test
display nqa result [ admin-name operation-tag ] [ |
{ begin | exclude | include } regular-expression ]
Display statistics of test results for
the specified or all test groups
display nqa statistics [ admin-name operation-tag ] [ |
{ begin | exclude | include } regular-expression ]
Display NQA server status
display nqa server status [ | { begin | exclude |
include } regular-expression ]
Available in any
view
NQA configuration examples
ICMP echo test configuration example
Network requirements
As shown in Figure 42, configure NQA ICMP echo tests to test whether the NQA client (Device A) can
send packets through a specific next hop to the specified destination (Device B) and test the round-trip
time of the packets.
