131
To do… Use the command… Remarks
Configure the destination
address of probe packets
destination ip ip-address
Required
By default, no destination IP address is
configured.
Configure the source IP
address of probe packets
source ip ip-address
Optional
By default, no source IP address is specified.
The source IP address must be the IP address of a
local interface. The local interface must be up;
otherwise, no probe packets can be sent out.
Configure optional
parameters
See “Configuring optional
parameters for an NQA
test group”
Optional
Configuring the collaboration function
Collaboration is implemented by establishing reaction entries to monitor the detection results of a test
group. If the number of consecutive probe failures reaches the threshold, the configured action is
triggered.
Follow these steps to configure the collaboration function:
To do… Use the command… Remarks
Enter system view system-view —
Enter NQA test group view
nqa entry admin-name
operation-tag
—
Enter test type view of the test
group
type { dhcp | dlsw | dns | ftp |
http | icmp-echo | snmp | tcp |
udp-echo }
The collaboration function is not
supported in UDP jitter and voice
tests.
Configure a reaction entry
reaction item-number
checked-element probe-fail
threshold-type consecutive
consecutive-occurrences
action-type trigger-only
Required
Not created by default.
You cannot modify the content of
an existing reaction entry.
Exit to system view quit —
Configure a track entry and
associate it with the reaction entry
of the NQA test group
track entry-number nqa entry
admin-name operation-tag
reaction item-number
Required
Not created by default.
Configuring threshold monitoring
Configuration prerequisites
Before you configure threshold monitoring, complete the following tasks:
• Configure the destination address of the trap message by using the snmp-agent target-host
command. For more information about the snmp-agent target-host command, see Network
Management and Monitoring Command Reference.
• Create an NQA test group and configure the related parameters.
