Configuring threshold monitoring
Follow these steps to configure threshold monitoring:
To do… Use the command… Remarks
Enter system view system-view —
Enter NQA test group view nqa entry admin-name operation-tag —
Enter test type view of the test
group
type { dhcp | dlsw | dns | ftp | http | icmp-echo
| snmp | tcp | udp-echo | udp-jitter | voice }
—
Configure to send traps to the
network management server under
specified conditions
reaction trap { probe-failure
consecutive-probe-failures | test-complete |
test-failure cumulate-probe-failures }
Configure a reaction entry for
monitoring the probe duration of a
test (not supported in UDP jitter and
voice tests)
reaction item-number checked-element
probe-duration threshold-type { accumulate
accumulate-occurrences | average | consecutive
consecutive-occurrences } threshold-value
upper-threshold lower-threshold [ action-type
{ none | trap-only } ]
Configure a reaction entry for
monitoring the probe failure times
(not supported in UDP jitter and
voice tests)
reaction item-number checked-element probe-fail
threshold-type { accumulate
accumulate-occurrences | consecutive
consecutive-occurrences } [ action-type { none |
trap-only } ]
Configure a reaction entry for
monitoring packet round-trip time
(only supported in UDP jitter and
voice tests)
reaction item-number checked-element rtt
threshold-type { accumulate
accumulate-occurrences | average }
threshold-value upper-threshold lower-threshold
[ action-type { none | trap-only } ]
Configure a reaction entry for
monitoring the packet loss in each
test (only supported in UDP jitter
and voice tests)
reaction item-number checked-element
packet-loss threshold-type accumulate
accumulate-occurrences [ action-type { none |
trap-only } ]
Configure a reaction entry for
monitoring one-way delay jitter
(only supported in UDP jitter and
voice tests)
reaction item-number checked-element { jitter-ds
| jitter-sd } threshold-type { accumulate
accumulate-occurrences | average }
threshold-value upper-threshold lower-threshold
[ action-type { none | trap-only } ]
Configure a reaction entry for
monitoring the one-way delay
(only supported in UDP jitter and
voice tests)
reaction item-number checked-element { owd-ds
| owd-sd } threshold-value upper-threshold
lower-threshold
Configure a reaction entry for
monitoring the ICPIF value (only
supported in voice tests)
reaction item-number checked-element icpif
threshold-value upper-threshold lower-threshold
[ action-type { none | trap-only } ]
Configure a reaction entry for
monitoring the MOS value (only
supported in voice tests)
reaction item-number checked-element mos
threshold-value upper-threshold lower-threshold
[ action-type { none | trap-only } ]
Required
Configure to send
traps.
No traps are sent to
the network
management server
by default.
