62
NOTE:
Each
view-name oid-tree
pair represents a view record. If you specify the same record with different MIB
subtree masks multiple times, the last configuration takes effect. Except the four subtrees in the default MIB
view, you can create up to 16 unique MIB view records.
Configuring basic SNMPv1 or SNMPv2c settings
Follow these steps to configure basic SNMPv1 or SNMPv2c settings:
To do… Use the command… Remarks
Enter system view system-view —
Enable the SNMP agent snmp-agent
Optional
Disabled by default.
You can also enable the SNMP
agent service by using any
command that begins with
snmp-agent except the snmp-agent
calculate-password and
snmp-agent ifmib long-ifindex
enable commands.
Configure system information
for the SNMP agent
snmp-agent sys-info { contact
sys-contact | location sys-location |
version { all |{ v1 | v2c | v3 }* } }
Required
By default, the contact is Hangzhou
H3C Tech. Co.,Ltd., the physical
location is Hangzhou, China, and
the protocol version is SNMPv3.
Configure the local engine ID snmp-agent local-engineid engineid
Optional
The default local engine ID is the
company ID plus the device ID.
Create or update a MIB view
snmp-agent mib-view { excluded |
included } view-name oid-tree [ mask
mask-value ]
Optional
By default, the MIB view
ViewDefault is predefined and its
OID is 1.
Configure SNMP access right
Approach 1: Create an SNMP
community
snmp-agent community { read | write }
community-name [ acl acl-number |
mib-view view-name ]*
Approach 2: Create an SNMP group,
and add a user to the SNMP group
1. snmp-agent group { v1 | v2c }
group-name [ read-view
read-view ] [ write-view write-view ]
[ notify-view notify-view ] [ acl
acl-number ]
2. snmp-agent usm-user { v1 | v2c }
user-name group-name [ acl
acl-number ]
Required
Use either approach.
By default, no SNMP group exists.
In approach 2, the username is
equivalent to the community name
in approach 1, and must be the
same as the community name
configured on the NMS.
