61
To do… Use the command… Remarks
Enable the SNMP agent snmp-agent
Optional
Disabled by default.
You can also enable the SNMP
agent by using any command that
begins with snmp-agent except the
snmp-agent calculate-password
and snmp-agent ifmib long-ifindex
enable commands.
Configure system information for
the SNMP agent
snmp-agent sys-info { contact
sys-contact | location sys-location
| version { all | { v1 | v2c |
v3 }* } }
Optional
By default, the contact is Hangzhou
H3C Tech. Co.,Ltd., the physical
location is Hangzhou, China, and
the protocol version is SNMPv3.
Configure the local engine ID
snmp-agent local-engineid
engineid
Optional
The default local engine ID is the
company ID plus the device ID.
Create or update a MIB view
snmp-agent mib-view { excluded |
included } view-name oid-tree
[ mask mask-value ]
Optional
By default, the MIB view
ViewDefault is predefined and its
OID is 1.
Configure an SNMPv3 group
snmp-agent group v3 group-name
[ authentication | privacy ]
[ read-view read-view ]
[ write-view write-view ]
[ notify-view notify-view ] [ acl
acl-number ]
Required
Convert a plain text key to an
encrypted key
snmp-agent calculate-password
plain-password mode { 3desmd5 |
3dessha | md5 | sha }
{ local-engineid |
specified-engineid engineid }
Optional
Add a user to the SNMPv3 group
snmp-agent usm-user v3
user-name group-name [ [ cipher ]
authentication-mode { md5 | sha }
auth-password [ privacy-mode
{ 3des | aes128 | des56 }
priv-password ] ] [ acl acl-number ]
Required
If the cipher keyword is specified,
the arguments auth-password and
priv-password are considered as
encrypted keys.
Configure the maximum size (in
bytes) of SNMP packets for the
SNMP agent
snmp-agent packet max-size
byte-count
Optional
By default, the SNMP agent can
receive and send the SNMP
packets up to 1,500 bytes.
CAUTION:
After you change the local engine ID, the existing SNMPv3 users become invalid, and you must re-create
the SNMPv3 users.
