5.6 - Heating - Eberspächer type
Another brand of heater can be installed.
For its operation, consult the user's manual.
Before commissioning the heater, check that :
– The heating vents are not blocked.
– There are no heat-sensitive elements in front of the heating
vents.
22°C20min
1
4
2
3
5
1 Heating control
2 Return button
3 Control knob
4 Display unit
5 Light ring
The heating control is installed to the right of the sliding door.
5.6.1 - Description of the display unit
22°C20min
2
1
1 Menu bar
2 Status bar
The display is backlit during operation or when the heater is on.
The display goes out aer approx. 30 seconds if :
– No settings are made.
– The heater is inactive.
The heating control then switches to standby mode.
An summary screen appears before switching to standby mode.
Menu bar
Symbol Description Symbol Description
Heating Settings
Ventilation Timer
