5.2.2 - Closure
The canvas must always be stored dry. If the canvas must be
put away damp, dry it as soon as possible to prevent the risk of
deterioration.
It is strictly forbidden to place a tensioning device around the canvas
to facilitate folding. This may cause damage to the canvas and
invalidate the warranty.
1
4
5
6
2
3
1 Handle
2 Canvas
3 Curtain
4 Clamp tting
5 Safety strap
6 Closure tab
To close the pop-up roof:
■ Park the vehicle in a location sheltered from wind.
■ Open the sliding side door.
■ Close the curtains and the mosquito nets of the canvas.
■ Take care to leave nothing on the mattress (quilt, duvet, pillow, etc.)
■ Check that the mattress is properly positioned in its box.
■ Check that the clamp ttings are all in position on the magnetic clamps.
■ Detach the roof lining and allow it to hang until complete closure is
achieved.
■ Lower the bed again.
■ Pull evenly on the roof handles to close it.
■ Pull the canvas inside the vehicle to prevent it from being damaged by the
mechanical components such as pantographs etc.
■ Roll the canvas near the clamp ttings so that the canvas will not come into
contact with the clamp ttings.
■ Detach the clamp ttings from the magnetic clamps.
■ Lock the clamp ttings in the closure tabs by turning the buttery nuts
clockwise.
■ Check that the roof is fully compressed.
■ Lock the security straps.
■ Using the Velcro strip, reposition the roof lining on the end of the bed.
