Battery voltage monitoring
The instrumentation and control panel lets you check the engine battery voltage
and cabin battery voltage.
7
12
8
12
12V
PC210
5
25
ext.
T
1
1
4
5
2
3
1
1 Battery voltage monitoring button
2 Engine battery voltage
3 Cabin battery voltage
4 Engine battery pictogram
5 Cabin battery pictogram
■ Press the battery voltage monitoring button (1) to display:
– The engine battery voltage (2).
The "engine battery" pictogram (4) is displayed on the screen.
– The cabin battery voltage (3).
The "cabin battery" pictogram (5) is displayed on the screen.
3.12.3 - Refrigerator
Door locking system
TO LOCK
TO VENT
2
A
B
1
1 Refrigerator
2 Door locking system
A Standard operating position
B Aeration position
■ Check that the door closes properly and that its locking system is set to
position "A" (to the le, position: "TO LOCK").
