Sliding the bench forwards:
– Take care not to strike the front right riser and the front seats.
– Take care not to strike the door stop of the sliding side door.
Sliding the bench towards the rear:
– Take care not to strike the rear right riser of the boot.
When sliding the bench, check that it does not rub against the
kitchen unit.
■ Use your foot to press the lever (1) to lock the bench in the desired position
in the oor rails.
Before resuming your journey, check that the bench is properly
locked.
5.1.3 - Installing the table
1
3
2
1 Tabletop
2 Tripod
3 Tube
A removable table is delivered with the vehicle. It can be used either in the
kitchen area inside the vehicle, or outside.
Its component parts are stowed in the rear hold.
■ Remove the table parts from the hold.
– The tabletop.
– The tripod.
– The tube.
A B
1
3
2
3
1 Tabletop
2 Tripod
3 Tube
■ Deploy the tripod (2).
■ Fit the tube (3) in the tripod (2).
■ Fit the tabletop (1) in the tube (3).
