1-8 Cabling and Wiring Requirements
HN4000 Hardware Installation Guide 920550-5020 Rev 14
Intra-Building Port Warning
StackPort** StackPort
Proprietaryshieldedcable
a
CBL101-0017-42
7inches(17cm)
CBL101-0003-12
3feet(0.9m)
CBL101-0010-12
10feet(3m)
MLTport** CustomerDefined CAT‐5unshieldedcable N/A
RS‐232Consoleport** Laptopor
Management
Terminal
CAT‐5shieldedcable
b
orshieldedserial
cable
N/A
a. StackingcablesmustbeprovidedbyHatterasNetworks.
b. ThefollowingCiscoSystems“CiscoBlueConsoleCables”canbeusedtoconnectalaptoptotheRJ‐45craftport:
72‐3383‐01cableor72‐1259‐01cablewith74‐0495‐01adapter.(Thiscableisnot
shieldedandmustnotbeusedfor
permanentinstallation.)
The following HN4000 ports are suitable for connection to intrabuilding or unexposed wiring or
cabling only:
• 100/1000BASE-T high-speed uplink port
• 10/100 MGMT management port
• Alarm port
• RS-232 console port
• MLT port
• Stack ports
These intra-building ports of the equipment or subassembly must not be metallically connected to
interfaces that connect to the OSP or its wiring. These interfaces are described for use as intra-
building interfaces only (Type 2 or Type 4 ports as described in GR-1089-CORE, Issue 4) and
require isolation from the exposed OSP cabling. The addition of Primary Protectors is not suffi-
cient protection in order to connect these interfaces metallically to OSP wiring.
Table 1-5 HN4000 Cabling (Continued)
From HN4000
...
To... Cable Type Hatteras Networks
P/N
