Hatteras HN4000 User Manual

3-10 Metallic Loop Test Ports
HN4000 Hardware Installation Guide 920550-5020 Rev 14
3.8 Metallic Loop Test Ports
TheHN4000providesexternaltestaccessviatwoRJ‐45jackslabeled“IN”and“OUT”
(Figure 3‐10).YoucanusetheCLI’sconfigmltcommandtoconfigure2BASE‐TLportsforMLT
testingandtheshowmltcommandtodisplaytheresultsofaloopbacktest.
Figure 3-10 Metallic Loop Test Ports
3.9 Alarm Port
TheHN4000AlarmI/Oport(Figure 3‐11)isanRJ‐45connectorthatprovidesaninterfacefor
alarmsthatthedevicegenerates,aswellassupportinganinputforexternalalarms.Alarms
generatedbytheHN4000areavailableontheAlarmport’snormally‐openandnor‐
mally‐closedrelaycontacts.
Figure 3-11 Alarm Port
