3-6 Serial Craft Port
HN4000 Hardware Installation Guide 920550-5020 Rev 14
3.3.4 Rebooting the Device
Ifyoukeepthelamptestbuttonpressedfor10seconds,theswitchwillreboot,buttheswitch
IDwillnotbechangedandnoconfigurationwillbecleared.
3.4 Serial Craft Port
TheHN4000supportstheconnectionofalocalmaintenance(craft)terminalthroughaDB9
femaleconnectorwithanRS232interface.
3.5 10/100 Management Port and LEDs
TheHN4000connectstoanetworkmanagementnetworkthroughthe10/100MbpsManage
ment(MGMT)port(Figure 36).
Figure 3-6 10/100 Mbps Management Port
Table32describesthe managementport’stwostatusLEDs(LINKandACT).
Table 3-2 HN4000 Status LEDs
LED
Marking
LED State Description
LINK Off Noconnectionhasbeendetectedbetweenthe10/100Mbpsportandanetwork
device.
SolidGreen Acommunicationlinkhasbeenestablishedbetweenthe10/100Mbpsportanda
networkdevice(normaloperation).
ACT Off Notrafficisbeingsentorreceivedonthe10/100Mbpsport.
BlinkingGreen Blinksastrafficpasses
throughtheport.
