Hatteras HN4000 User Manual

Installing the Rack Mounting Brackets 2-5
920550-5020 Rev 14 HN4000 Hardware Installation Guide
2.4.3 Assembling the Brackets
Step 1. AssemblethemountingbracketstobothsidesoftheHN4000chassisusingtheeight
provided#6‐32Phillipsheadscrewsanda#2Phillipsscrewdriver.
Step 2. TightenthePhillipsheadscrewsto6‐10in‐lbs(0.7 ‐1.1Nm).
Figure 2‐4showsanANSI19”bracketmountedontherightside
ofachassis.
Figure 2-4 Right-Side ANSI 19” Bracket
Step 3. IftheHN4000istobeinstalledina23”ANSIrack,takesteps3a‐through‐3cbelow.
Otherwise,gotoStep4.
a. ReferringtoFigure 2‐5,orienttheendofanextenderbracketwiththedrilledand
tappedholesbehindtheleft‐side19”ANSIbracket.Notethatthe
extender
bracket’soffsetistowardthefrontoftheHN4000.
Figure 2-5 Orientation of Extender Brackets
Left-Side 19” Bracket
Right-Side 19” Bracket
Extender
Bracket
Extender
Bracket
