Cabling a High-Speed Network Module 4-5
920550-5020 Rev 14 HN4000 Hardware Installation Guide
4.2.2 Cabling a Dual 100/1000BASE-T High-Speed Network Module
PerformthefollowingstepstoconnectEthernetcablestoPort1and2ofa100/1000BASE‐T
high‐speednetworkmodule(HN4000‐GbT).ThecablesmustbeEthernetCAT‐5e(orbetter).
Step 1. VerifythattheEthernetcablesarelongenoughtomaintainaproperbendingradius
wherethecablesenterthe
frontoftheHN4000andarerou tedthroughacable‐guide
slotintheright‐sidemountingbracket.
Step 2. ConnectacabletoPort1and(optionally)toPort2ofthehigh‐speedmodule.
Step 3. DressthecablestotherightoftheHN4000andthroughacable‐guide
slotinthe
right‐sidemountingbracket.
Step 4. TerminatetheotherendoftheEthernetcablespercustomerrequirements.
End of Procedure
4.2.3 Cabling a Dual T3/E3 High-Speed Network Module
PerformthefollowingstepstoconnectcablestotheTXandRXportsofanUnchannelized
T3/E3‐TXmodule(HN4000‐TE3).
TheT3/E3‐TXmoduleisprovidedwithtwo10”(254mm)mini‐BNCtoBNCadaptercables.
Figure 4‐3showsanadaptercable.
Figure4‐4 Mini‐BNCtoBNCAdapter
CableforT3/E3‐TXModule
Mini-BNC Connector
BNC Connector
